HES Series

Up to 2 tons per day

HES Series

Up to 2 tons per day

The HES (Hi Efficiency) Series with a capacity range of 3000 to 4000 pounds of icer per day is the preferred choice of ice machine for thousands of food service applications worldwide. Heavy-duty industrial construction, automatic operation, energy efficiency and the best warranty in the business make the Vogt HES Series the only “clear” choice for your ice making needs.

All surfaces in contact with water or ice are of stainless steel or other rust-resistant materials. All HES Series machines are furnished with stainless steel panels as standard. Units are factory tested and adjusted for cylinder ice only and can be manually converted to crushed ice in the field if required. Unit can be set for crushed ice at the factory with no extra charge if specified on order.

Standard Features

  • Warranty: 25 Year Evaporator Warranty
  • Voltage: 208/230V, 3Ph, 60Hz
  • Refrigerant: 452A
  • Cutter for cylinder (default) or crushed ice operation
  • Copeland Performance Alert Power Monitor
  • Electronic ice bin thermostat
  • Stainless steal casings
  • Integral drip pan
  • Self-Diagnostic indicator light
  • Water-cooled or remote air-cooled operation
  • PLC controls

Options

  • Voltage – 460V, 3Ph, 60Hz
  • Voltage – 490V, 3Ph, 50Hz
  • Voltage – 200V, 3Ph, 50Hz
  • High ambient air-cooled condenser
  • Electro-fin coated condenser
  • High pressure (200psig) water condenser/regulator
  • Casing security screws (correctional usage)
  • Cutter for 1-1/2″ long ice remote switch box
  • Flush valve assembly
  • “CE” approval (400V, 50Hz only)
  • Canadian Registration Number (CRN)
  • Export crating (ISPM-15 Rated)

Standard Ice Sizes

  • Tube-Ice: Approximately 7/8″ diameter x 3/4″ long (S model)
  • Tube-Ice: Approximately 1 1/8″ diameter x 1″ long (M model)
  • Crushed Ice 3/16″ to 1/4″ thick on all models (approximately 32lbs./cubic foot)
